UNIOP eTOP133C-0050觸摸屏 PDF資料
1.產 品 資 料 介 紹：
中文資料：
一、產品概述
eTOP133C?0050 屬于 UniOP eTOP 系列，是一款帶 10.4 英寸 TFT 彩色觸摸屏的工業 HMI 面板，采用電阻式觸控技術，提供豐富通信接口與功能擴展，適合工業自動化控制系統。
二、主要技術參數（參考同系列規格）
顯示屏：10.4″ TFT 彩色 LCD
分辨率：640 × 480 像素（VGA）
觸控方式：電阻式觸摸屏
用戶存儲：約 64?MB 內存，用于程序與數據存儲
通信接口：內置以太網（10/100 Mbps）、USB 端口，支持 RS?232（打印機/PC）、RS?485（PLC），可插入模塊擴展現場總線如 Profibus DP、CANopen、DeviceNet、Interbus 等
電源輸入：24?V DC（±10?%）
環境溫度：常規工作溫度范圍約 0–45?°C
軟件支持：支持 UniOP Designer 或 JMobile 軟件平臺，擁有宏腳本、報警管理、歷史數據記錄、配方管理、多語言界面與報表功能
用戶界面功能：支持 SVG 矢量圖形、TrueType 字體、向量圖形繪制、UniNet 網絡(luò )通信協議
三、典型應用領域
中大型工業自動化控制
作為控制終端，在裝配線、泵站、包裝設備、CNC 機床等系統中執行監控與參數設置。過程監控與數據管理
提供報警記錄、趨勢繪圖、配方切換、多級密碼保護和報表打印功能，便于設備監調與維護追溯。樓宇自動化與能源管理
用于 HVAC、水處理、電力系統等場景的本地操作界面，實時顯示系統狀態并接入現場總線控制。系統集成與網絡(luò )通信接口擴展
通過 USB、以太網和現場總線模塊，可與 PLC、SCADA、OPC Server、UniNet 網絡(luò )系統集成，在分布式控制架構中溝通數據。維修與替代使用
由于該型號已停產，市場上常見庫存件或翻新件，適合作為早期 eTOP33C 面板的替代或維修備件。
英文資料：
1、 Product Overview
ETOP133C-0050 belongs to the UniOP eTOP series and is an industrial HMI panel with a 10.4-inch TFT color touch screen. It uses resistive touch technology and provides rich communication interfaces and functional extensions, making it suitable for industrial automation control systems.
2、 Main technical parameters (refer to specifications of the same series)
Display screen: 10.4 "TFT color LCD
Resolution: 640 × 480 pixels (VGA)
Touch mode: resistive touch screen
User storage: Approximately 64 MB of memory for program and data storage
Communication interface: Built in Ethernet (10/100 Mbps), USB port, supports RS-232 (printer/PC), RS-485 (PLC), can insert modules to expand fieldbus such as Profibus DP, CANopen, DeviceNet, Interbus, etc
Power input: 24V DC (± 10%)
Environmental temperature: The normal operating temperature range is about 0-45 ° C
Software support: Supports UniOP Designer or JMobile software platforms, with macro scripting, alarm management, historical data recording, recipe management, multilingual interface, and reporting functions
User interface features: Supports SVG vector graphics, TrueType fonts, vector graphics drawing, UniNet network communication protocol
3、 Typical application areas
Large scale industrial automation control
As a control terminal, it performs monitoring and parameter setting in systems such as assembly lines, pump stations, packaging equipment, CNC machine tools, etc.
Process monitoring and data management
Provide alarm recording, trend plotting, recipe switching, multi-level password protection, and report printing functions for equipment monitoring, debugging, maintenance, and traceability.
Building Automation and Energy Management
A local operating interface for HVAC, water treatment, power systems, and other scenarios, displaying system status in real-time and connected to fieldbus control.
System integration and network communication interface expansion
Through USB, Ethernet, and fieldbus modules, it can be integrated with PLC, SCADA, OPC Server, UniNet network systems to communicate data in a distributed control architecture.
Repair and Alternative Use
Due to the discontinuation of this model, it is a common stock or refurbished part in the market, suitable as a replacement or repair spare part for early eTOP33C panels.
2.產 品 展 示
