UNIOP ETOP05-0045 操作界面 PDF資料
1.產 品 資 料 介 紹：
中文資料：
UniOP ETOP05-0045 操作界面簡介
一、產品概述
UniOP ETOP05-0045 是一款緊湊型工業人機界面（HMI）觸摸面板，配備 5.7 英寸單色液晶顯示屏，適合中小型自動化系統的控制與監控需求。
二、主要技術參數
顯示屏：5.7 英寸單色 LCD，分辨率 320×240 像素
觸摸方式：電阻式觸摸屏
背光：白色 LED 背光
存儲容量：約 32MB 用戶程序空間
電源輸入：24V DC，約 0.6A
通信接口：支持 RS-232、RS-422、RS-485，可連接 PC 或打印機；支持額外的以太網模塊擴展
軟件支持：兼容 UniOP Designer 6，支持圖形化設計、宏命令、報警管理、歷史數據、配方管理及多語言界面
三、典型應用領域
小型工業自動化設備控制，如機械設備參數設置與狀態監控
樓宇自動化系統，包括空調、電梯和水泵等控制
過程監控與數據管理，支持報警記錄、趨勢顯示、配方切換等功能
系統集成，支持多種通信協議與現場總線擴展
舊設備維修和替代應用
英文資料：
Introduction to UniOP ETOP05-0045 Operating Interface
1、 Product Overview
UniOP ETOP05-0045 is a compact industrial human-machine interface (HMI) touch panel equipped with a 5.7-inch monochrome LCD display screen, suitable for the control and monitoring needs of small and medium-sized automation systems.
2、 Main technical parameters
Display screen: 5.7-inch monochrome LCD with a resolution of 320 × 240 pixels
Touch mode: resistive touch screen
Backlight: White LED backlight
Storage capacity: approximately 32MB user program space
Power input: 24V DC, approximately 0.6A
Communication interface: Supports RS-232, RS-422, RS-485, can be connected to PC or printer; Support additional Ethernet module expansion
Software support: Compatible with UniOP Designer 6, supporting graphical design, macro commands, alarm management, historical data, recipe management, and multilingual interface
3、 Typical application areas
Control of small industrial automation equipment, such as parameter setting and status monitoring of mechanical equipment
Building automation system, including control of air conditioning, elevators, water pumps, etc
Process monitoring and data management, supporting functions such as alarm recording, trend display, formula switching, etc
System integration, supporting multiple communication protocols and fieldbus extensions
Old equipment maintenance and replacement applications
2.產 品 展 示
