UNIOP ETOP507U2P3觸摸屏面板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
UniOP eTOP507U2P3 觸摸屏面板簡介
一、產品概述
eTOP507U2P3 屬于 UniOP eTOP 500 系列，是一款工業級人機界面（HMI）觸摸觸控面板。搭載 7 英寸彩色寬屏顯示，設計用于復雜的工業自動化應用場景。
二、主要技術參數
顯示屏：7 英寸 TFT 彩色寬屏（16:9），分辨率 800×480 像素
觸控方式：電阻式電容混合觸摸或電阻式觸摸（視具體批次而定）
內存：256?MB RAM，128?MB Flash，可運行復雜界面和腳本
通信接口：雙以太網（10/100?Mbps）、USB 主機端口、USB 設備端口、SD 卡插槽
擴展支持：可使用可插拔模塊（如 Profibus、CANopen、DeviceNet）擴展現場總線功能
電源輸入：24?V DC
環境適應：支持 IP65 前面板防護，耐塵防水；工作溫度范圍一般為 0–50?°C
軟件支持：兼容 JMobile 平臺，具備矢量圖形、報警歷史、趨勢繪圖、配方管理、多語言配置、宏命令等高級功能
三、典型應用場景
制造業自動化現場操作與監控
過程控制系統中的實時數據展示與設備設置
設備報警、趨勢記錄與報表功能應用
樓宇自動化系統中的暖通與配電控制
集中控制架構中多裝置互聯（借助 UniNet 或 OPC Server）
英文資料：
Introduction to UniOP eTOP507U2P3 Touch Screen Panel
1、 Product Overview
ETOP507U2P3 belongs to the UniOP eTOP 500 series and is an industrial grade human-machine interface (HMI) touch panel. Equipped with a 7-inch color widescreen display, designed for complex industrial automation application scenarios.
2、 Main technical parameters
Display screen: 7-inch TFT color widescreen (16:9), resolution 800 × 480 pixels
Touch mode: resistive capacitive hybrid touch or resistive touch (depending on the specific batch)
Memory: 256 MB RAM, 128 MB Flash, capable of running complex interfaces and scripts
Communication interface: Dual Ethernet (10/100 Mbps), USB host port, USB device port, SD card slot
Extended support: Can use pluggable modules (such as Profibus, CANopen, DeviceNet) to expand fieldbus functionality
Power input: 24V DC
Environmental adaptation: Supports IP65 front panel protection, dust and water resistance; The working temperature range is generally 0-50 ° C
Software support: compatible with JMobile platform, with advanced functions such as vector graphics, alarm history, trend drawing, recipe management, multilingual configuration, macro commands, etc
3、 Typical application scenarios
Manufacturing automation on-site operation and monitoring
Real time data display and equipment settings in process control systems
Application of device alarm, trend recording and reporting functions
HVAC and Distribution Control in Building Automation Systems
Multi device interconnection in centralized control architecture (using UniNet or OPC Server)
2.產 品 展 示
