KEBA K2-400 SC440/A通信模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
KEBA K2-400 SC440/A 通信模塊** 是 KEBA 自動化系統中用于主控單元與外部設備之間進行工業通信的關鍵模塊，支持多種通信協議與現場總線連接方式。該模塊廣泛應用于注塑機、包裝機、機器人系統以及自動化生產線中，作為數據交互與指令傳輸的橋梁。
技術參數：
模塊類型：工業通信擴展模塊
接口類型：支持 RS-232/RS-485、CAN、Ethernet（依具體配置）
通信協議：支持 Modbus RTU、CANopen、EtherNet/IP、PROFIBUS DP 等
數據傳輸速率：最高可達 12 Mbps（取決于接口類型）
電源供電：由控制系統母板供電（通常為 5V 或 24V DC）
安裝方式：插入式或背板安裝，適配 KEBA KeControl 系列
模塊尺寸：標準工業尺寸，便于集成至控制柜
工作環境溫度：0°C 至 +50°C
電氣隔離：各通信端口具備電氣隔離，增強抗干擾能力
狀態指示：LED 指示燈顯示通信狀態和故障信息
應用領域：
1. 注塑與成型設備通信系統
用于主控制器與溫控模塊、驅動器、閥島、I/O 擴展模塊間的數據交換。
實現控制閉環內各部件的高效協調。
2. 包裝與輸送自動化系統
連接傳感器、執行器、視覺系統等外部設備，實現快速通信響應。
用于同步多個設備狀態、位置與指令。
3. 機器人集成系統
支持與多品牌 PLC、驅動器及上位機系統（SCADA）通信。
提供高速且穩定的現場總線連接。
4. MES/ERP 系統數據接入
實現現場控制系統與工廠信息管理系統之間的數據橋接。
支持通過以太網或串口方式上傳設備運行數據。
5. 工業網關與遠程監控
作為網關模塊，橋接多種通信標準，便于系統遠程訪問和運維。
英文資料：
The KEBA K2-400 SC440/A communication module * * is a key module used in the KEBA automation system for industrial communication between the main control unit and external devices, supporting multiple communication protocols and fieldbus connection methods. This module is widely used in injection molding machines, packaging machines, robot systems, and automated production lines as a bridge for data exchange and instruction transmission.
Technical parameters:
Module type: Industrial Communication Expansion Module
Interface type: Supports RS-232/RS-485, CAN, Ethernet (depending on specific configuration)
Communication protocol: Supports Modbus RTU, CANopen, EtherNet/IP, PROFIBUS DP, etc
Data transmission rate: up to 12 Mbps (depending on interface type)
Power supply: Powered by the control system motherboard (usually 5V or 24V DC)
Installation method: plug-in or backplate installation, compatible with KEBA KeControl series
Module size: Standard industrial size, easy to integrate into control cabinets
Working environment temperature: 0 ° C to+50 ° C
Electrical isolation: Each communication port has electrical isolation to enhance anti-interference capability
Status indication: LED indicator light displays communication status and fault information
Application areas:
1. Injection molding and molding equipment communication system
Used for data exchange between the main controller and temperature control modules, drivers, valve islands, and I/O expansion modules.
Realize efficient coordination of various components within the control loop.
2. Packaging and Conveyor Automation System
Connect external devices such as sensors, actuators, and vision systems to achieve fast communication response.
Used to synchronize the status, location, and instructions of multiple devices.
3. Robot integrated system
Support communication with multiple brands of PLCs, drivers, and SCADA systems.
Provide high-speed and stable fieldbus connections.
4. MES/ERP system data access
Realize data bridging between on-site control system and factory information management system.
Support uploading device operation data through Ethernet or serial port.
5. Industrial gateway and remote monitoring
As a gateway module, it bridges multiple communication standards, facilitating remote access and operation of the system.
2.產 品 展 示
