KEBA T50-ADP示教器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
KEBA T50-ADP 示教器** 是 KEBA 推出的中高端人機交互設備，用于機器人系統、注塑設備、自動化生產線等工業場景中的程序編寫、路徑示教、參數設置與實時監控。作為 T50 系列的一員，T50-ADP 具備觸控屏、功能按鍵、安全控制元件等標準功能，支持多語言操作界面，適用于多類型自動化設備。
技術參數：
顯示屏：7 英寸 TFT 彩色液晶觸摸屏
分辨率：800×480（WVGA）
觸控方式：電阻式觸摸屏，支持戴手套操作
控制按鍵：
多個可編程功能按鍵
方向控制、確認、啟動/停止等物理按鍵
安全功能：
紅色急停按鈕（符合 EN ISO 13850）
三段式使能開關（左手或右手持握）
通信接口：
USB 接口（程序導入導出）
以太網或專用通信端口（連接控制器）
供電方式：通過主系統供電，典型 24V DC
結構設計：
工業級耐沖擊外殼
防塵防油設計，適應惡劣環境
重量：約 1.2～1.5 kg（適合手持長期操作）
工作環境溫度：0°C 至 +50°C
應用領域：
1. 工業機器人路徑示教
用于六軸或多軸工業機器人示教路徑點位、軌跡規劃、速度調試等。
2. 注塑與橡膠成型機
實時監控鎖模、注射、保壓等工藝過程參數，進行快捷修改與操作。
3. 自動化生產線調試
控制輸送、裝配、上下料等子系統設備，便于故障排查和狀態檢查。
4. 包裝與貼標設備人機操作
對熱封、貼標、送膜等功能進行人工輔助操作與參數設定。
5. 系統維護與故障診斷
支持設備日志查看、報警管理、設備測試指令發送等運維操作。
英文資料：
The KEBA T50-ADP teaching pendant is a mid to high end human-machine interaction device launched by KEBA, used for programming, path teaching, parameter setting, and real-time monitoring in industrial scenarios such as robot systems, injection molding equipment, and automated production lines. As a member of the T50 series, T50-ADP is equipped with standard functions such as touch screen, function buttons, and safety control components. It supports multiple language operation interfaces and is suitable for various types of automation equipment.
Technical parameters:
Display screen: 7-inch TFT color LCD touch screen
Resolution: 800 × 480 (WVGA)
Touch mode: resistive touch screen, supports glove operation
Control buttons:
Multiple programmable function keys
Physical buttons for direction control, confirmation, start/stop, etc
Security function:
Red emergency stop button (compliant with EN ISO 13850)
Three stage enable switch (held with left or right hand)
Communication interface:
USB interface (program import and export)
Ethernet or dedicated communication port (connected to controller)
Power supply method: Powered by the main system, typically 24V DC
Structural design:
Industrial grade impact resistant shell
Dustproof and oil proof design, suitable for harsh environments
Weight: Approximately 1.2-1.5 kg (suitable for long-term handheld operation)
Working environment temperature: 0 ° C to+50 ° C
Application areas:
1. Industrial robot path teaching
Used for teaching path points, trajectory planning, speed debugging, etc. of six axis or multi axis industrial robots.
2. Injection molding and rubber forming machines
Real time monitoring of process parameters such as mold locking, injection, and pressure maintenance for quick modification and operation.
3. Debugging of automated production line
Control subsystem equipment such as conveying, assembly, loading and unloading to facilitate troubleshooting and status checks.
4. Packaging and labeling equipment human-machine operation
Manually assist in the operation and parameter setting of functions such as heat sealing, labeling, and film feeding.
5. System maintenance and fault diagnosis
Support operation and maintenance operations such as device log viewing, alarm management, and device testing instruction sending.
2.產 品 展 示
