KEBA E-8-ANALOG/C控制板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
KEBA E-8-ANALOG/C 是 KEBA 自動化系統中的一款模擬量輸入/輸出控制板，通常用于采集外部模擬信號（如電壓、電流、溫度）并將其傳輸給主控制系統進行處理，也可作為模擬信號的輸出接口控制外部設備。此類模塊常用于注塑、包裝、機器人系統中的過程控制環節。
技術參數：
模塊類型：模擬量輸入/輸出控制板
通道數量：8 路通道（可配置為輸入或輸出，具體版本可能略有不同）
輸入信號類型：
電壓輸入：0～10V，±10V
電流輸入：0～20 mA，4～20 mA（可選）
輸出信號類型：
電壓輸出：0～10V
電流輸出：4～20 mA（僅限支持版本）
A/D 轉換精度：12～16 位（視型號而定）
響應時間：典型小于 10 ms
絕緣方式：通道對系統隔離，抗干擾能力強
供電電壓：24V DC（±10%）
狀態顯示：板載 LED 狀態指示燈
安裝方式：插板式或背板連接
工作環境：溫度 0～50°C，濕度 < 85%（無凝露）
應用領域：
1. 注塑/橡膠機械溫度與壓力控制
采集熱電偶放大器輸出、電壓型壓力傳感器信號
控制比例閥、加熱器等設備的模擬驅動信號輸出
2. 過程控制系統
用于采集流量、液位、速度、張力等連續變量
精確輸出控制信號用于調節閥、變頻器、比例執行器等
3. 包裝與印刷設備
控制熱封溫度、張力反饋、伺服電壓調節等
實現同步控制與模擬反饋回路閉環控制
4. 工業機器人平臺
接收外部傳感器或力控裝置的模擬輸入信號
輸出模擬控制信號至末端執行器、電動夾爪等
5. 設備狀態采集與控制系統集成
采集設備狀態或環境變量（溫度、電流、電壓）用于系統預警或分析
輸出信號用于外部設備驅動或聯動邏輯控制
英文資料：
KEBA E-8-ANALOG/C is an analog input/output control board in KEBA automation systems, typically used to collect external analog signals (such as voltage, current, temperature) and transmit them to the main control system for processing. It can also serve as an output interface for analog signals to control external devices. This type of module is commonly used in the process control links of injection molding, packaging, and robot systems.
Technical parameters:
Module type: Analog input/output control board
Number of channels: 8 channels (configurable as input or output, specific versions may vary slightly)
Input signal type:
Voltage input: 0-10V, ± 10V
Current input: 0-20 mA, 4-20 mA (optional)
Output signal type:
Voltage output: 0-10V
Current output: 4-20 mA (only for supported versions)
A/D conversion accuracy: 12-16 bits (depending on the model)
Response time: typically less than 10 ms
Insulation method: The channel isolates the system and has strong anti-interference ability
Power supply voltage: 24V DC (± 10%)
Status display: onboard LED status indicator light
Installation method: plug-in or backplane connection
Working environment: temperature 0-50 ° C, humidity<85% (no condensation)
Application areas:
1. Temperature and pressure control of injection molding/rubber machinery
Collect thermocouple amplifier output and voltage type pressure sensor signal
Analog drive signal output for controlling proportional valves, heaters, and other equipment
2. Process control system
Used for collecting continuous variables such as flow rate, liquid level, speed, tension, etc
Accurate output control signals are used to regulate valves, frequency converters, proportional actuators, etc
3. Packaging and printing equipment
Control heat sealing temperature, tension feedback, servo voltage regulation, etc
Implement synchronous control and analog feedback loop closed-loop control
4. Industrial Robot Platform
Receive analog input signals from external sensors or force control devices
Output analog control signals to end effectors, electric grippers, etc
5. Integration of equipment status acquisition and control system
Collect device status or environmental variables (temperature, current, voltage) for system warning or analysis
Output signals are used for external device driving or linkage logic control
2.產 品 展 示
