KEBA D1633C控制電路板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
KEBA D1633C 控制電路板是 KEBA 工業自動化系統中的一款核心嵌入式控制模塊，主要用于處理現場信號、協調外設接口以及實現關鍵邏輯控制功能。它通常集成在 KEBA 的注塑機、自動化單元、伺服控制系統或嵌入式控制平臺中，作為內部控制系統的一部分。
該板卡可能屬于 KEBA KeControl、KePlast 或 KeMotion 系統中的擴展功能模塊，負責數字控制、模擬信號處理或總線通信任務。
技術參數：
注：由于 D1633C 為 KEBA 內部型號，其部分具體參數取決于定制版本或所屬產品系列，下列為典型特征：
電路板類型：多功能工業控制板（可定制 I/O 與通信功能）
信號處理能力：支持數字量輸入輸出、模擬量處理及通訊接口擴展
主控芯片：工業級嵌入式 MCU 或 FPGA（依配置）
通信支持：
可選 RS232、RS485、CAN、Ethernet、SPI 等接口
與主控系統通過背板總線或扁平排線連接
輸入/輸出通道（依配置）：
數字輸入（24V DC）×8～16
數字輸出（繼電器或晶體管）×8～16
模擬輸入（0–10V 或 4–20mA）×2～8
模擬輸出（0–10V）×2～4
供電電壓：24V DC（±10%）
工作溫度：0°C ～ +55°C
電路板結構：4層以上工業級 PCB，帶有防干擾保護
安裝方式：插拔式、螺絲孔固定或專用機箱卡槽安裝
狀態指示：板載 LED 指示運行狀態與通道狀態
應用領域：
1. 注塑控制系統（如 KePlast 平臺）
控制板用于處理射出、保壓、模具溫度調節等過程信號。
2. 包裝機械控制單元
實現高速傳感器輸入與執行器輸出控制，協調多軸同步。
3. 工業機器人嵌入式控制系統
用于處理編碼器反饋、伺服驅動控制及通信數據分發。
4. 運動控制平臺
管理伺服驅動器、信號接口與過程邏輯，實現精密控制。
5. 設備控制與數據采集系統（SCADA 接入）
執行數據采集任務，并通過通信接口上傳至主控制系統。
英文資料：
The KEBA D1633C control circuit board is a core embedded control module in KEBA industrial automation systems, mainly used for processing field signals, coordinating peripheral interfaces, and implementing key logic control functions. It is usually integrated into KEBA's injection molding machines, automation units, servo control systems, or embedded control platforms as part of the internal control system.
This board may belong to the extension function module in KEBA KeControl, KePlast, or KeMotion systems, responsible for digital control, analog signal processing, or bus communication tasks.
Technical parameters:
Note: As D1633C is an internal model of KEBA, some of its specific parameters depend on the customized version or the product series it belongs to. The following are typical features:
Circuit board type: Multi functional industrial control board (customizable with I/O and communication functions)
Signal processing capability: supports digital input/output, analog processing, and communication interface expansion
Main control chip: Industrial grade embedded MCU or FPGA (depending on configuration)
Communication support:
Optional RS232, RS485, CAN, Ethernet, SPI and other interfaces
Connected to the main control system through backplane bus or flat cable
Input/output channels (according to configuration):
Digital input (24V DC) × 8-16
Digital output (relay or transistor) x 8-16
Analog input (0-10V or 4-20mA) x 2-8
Analog output (0-10V) × 2-4
Power supply voltage: 24V DC (± 10%)
Working temperature: 0 ° C to+55 ° C
Circuit board structure: Industrial grade PCB with 4 or more layers, equipped with anti-interference protection
Installation method: plug-in, screw hole fixed or dedicated chassis card slot installation
Status indication: Onboard LED indicates operating status and channel status
Application areas:
1. Injection control system (such as KePlast platform)
The control board is used to process signals such as injection, holding pressure, and mold temperature adjustment.
2. Packaging machinery control unit
Realize high-speed sensor input and actuator output control, coordinate multi axis synchronization.
3. Embedded control system for industrial robots
Used for processing encoder feedback, servo drive control, and communication data distribution.
4. Motion control platform
Manage servo drives, signal interfaces, and process logic to achieve precise control.
5. Equipment Control and Data Acquisition System (SCADA Access)
Execute data collection tasks and upload them to the main control system through communication interfaces.
