Although all bits in the slave address modifier register
may be changed dynamically, they must be changed
only when the VMEchip has control of the VMEbus.
The recommended procedure for changing the slave
address modifier is:
a. Set the DWB bit in the requester configuration
register to 1.
b. Read the DHB status bit until it is 1.
c. Change the slave address modifier register.
d. Clear the DWB bit to 0. The register allows software to program the address
modifier code that is driven by the MVME147 during a
VMEbus cycle. These five bits, in conjunction with AMSEL, allow software to
select dynamically the address space that the master accesses
during VMEbus cycles. Setting any of these five bits to 1 causes
the master to drive the corresponding address modifier line to
high (if the AMSEL bit is set to 1).
Clearing any of the bits to 0 causes the master to drive the
corresponding line to low (if the AMSEL bit is set to 1).
These bits are cleared by SYSRESET.
Bit 7 Software uses the AMSEL control bit to define what is the
source of the AM code driven by the master during a VMEbus
cycle.
Setting the bit to 1 causes the master to drive the contents of the
lower six bits onto the address modifier lines. No attempt is
made to check the value stored in this register for reserved or
illegal address modifiers.
Clearing the AMSEL bit causes the master to determine the AM
code dynamically.
AMSEL should normally be cleared to 0. This bit is cleared by
SYSRESET. This register is used to enable the MC68030 to respond
to specific VMEbus interrupt requests. Note that the
master interrupt enable bit in the PCC must also be set
for VMEbus IRQs to get through to the MC68030.
Setting any of bits 1 through 7 unmasks an interrupt
request from the VMEbus IRQ signal at the
corresponding level. Keep in mind that only one
VMEbus master is allowed to handle each level of
VMEbus IRQ. The software should set these bits
accordingly. These bits are cleared by any reset.
