The ISF control bit allows other VMEbus masters to cause the
VMEchip to release its contribution to the VMEbus SYSFAIL*
line. This is provided so that software can determine how many
boards have failed. It should be noted that the ISF bit has no
effect on the BRDFAIL status bit. Setting the bit to 1 inhibits the
VMEchip from activating the VMEbus SYSFAIL* line. This bit is
cleared by SYSRESET. The SCON status bit is a reflection of the configuration of
header J3. When J3 pins 1 and 2 are connected, enabling the
MVME147 as system controller, the SCON bit is 1. Otherwise it
is 0.
Bit 7 The R&H bit allows other VMEbus masters to reset the
MVME147. The MVME147 is held in the reset state for as long
as the R&H bit is set. This bit is cleared by SYSRESET. 1. The GCSR Base Address Configuration Register
must be programmed to allow the GCSR set of registers
to respond to VMEbus accesses for this function to be
enabled.
2. If the MVME147 sets its own R&H, it causes itself to
be maintained in a reset state until some other master
clears the bit to 0.
3. Software must never activate R&H for shorter than
35 microseconds.
4. The R&H bit should not be set while the local MPU
is executing a VMEbus cycle.The MC68030 can both read and write to this register.
The VMEbus can only read it. This register allows the
software to uniquely identify boards. The whole
register is cleared by SYSRESETIntroduction
This chapter provides a functional description of the MVME147.
The functional description provides an overview of the module,
followed by a detailed description of each section of the module.
The block diagram of the MVME147 is shown in Figure 5-1
