UDD406A 3BHE041465P201控制卡件，ABB使用產品
MC68030微處理器MC68030是MVME147的主處理器。MC68030具有片上指令和數據緩存。MVME147防止MC68030，用于緩存對本地以外任何其他設備的訪問DRAM通過在訪問。參見MC68030增強型32位微處理器用戶手冊。MC68030包括軟件復位指令；然而MVME147不支持此指令。MC68882 FPCMC68882浮點協處理器（FPC）連接到MC68030作為32位端口。
UDD406A 3BHE041465P201控制卡件其運行頻率與MC68030。參考MC68881/MC68882浮點協處理器用戶手冊，詳細說明其操作。VMEchip公司VMEchip是一種專用集成電路（ASIC）設備減少與VMEbus接口所需的不動產。它提供以下內容：
? VMEbus系統控制器功能? VMEbus中斷處理程序
? VMEbus和本地超時功能? MC68030至VMEbus接口
? VMEbus控制信號驅動器和接收器。功能描述MVME147是一個完整的微機系統。模塊包含以下內容? MC68030微處理器? 4MB或更大的DRAM（可從VMEbus訪問）
? MC68882浮點協處理器? VMEchip公司
? 4088字節的靜態RAM，帶備用電池? 帶備用電池的時鐘
? 具有EIA-232-D接口的四個串行端口，? 雙刻度計時器
? 看門狗定時器? 四個ROM插槽? SCSI總線與DMA的接口
? 以太網收發器接口? Centronics打印機端口? A32/D32 VMEbus接口
? VMEbus系統控制器? 眾多控制功能
注意，MVME147上不包括以太網接口-010
MC68030 MPU
The MC68030 is the main processor of the MVME147. The MC68030
has onchip instruction and data caches. The MVME147 prevents the
MC68030 from caching accesses to any other device than local
DRAM by activating the cache inhibit in pin (CIIN*) during the
accesses. Refer to the MC68030 Enhanced 32-Bit Microprocessor
User's Manual.
The MC68030 includes a software reset instruction; however, the
MVME147 does not support this instruction.
MC68882 FPC
The MC68882 Floating-Point Coprocessor (FPC) is connected to the
MC68030 as a 32-bit port. It runs at the same frequency as the
MC68030. Refer to the MC68881/MC68882 Floating-Point
Coprocessor User's Manual for a detailed description of its operation.
VMEchip
The VMEchip is an Application Specific IC (ASIC) device designed
to reduce the real estate required to interface with the VMEbus. It
provides the following:
? VMEbus system controller functions
? VMEbus interrupt handler
? VMEbus and local time-out functions
? MC68030 to VMEbus interface
? VMEbus control signal drivers and receivers. Functional Description
The MVME147 is a complete microcomputer system. The module
contains the following:
? MC68030 MPU
? 4MB or more of DRAM (accessible from the VMEbus)
? MC68882 Floating-Point Coprocessor
? VMEchip
? 4088 bytes of static RAM with battery backup
? Time-of-day clock with battery backup
? Four serial ports with EIA-232-D interface,
? Two tick timers
? Watchdog timer
? Four ROM sockets
? SCSI bus interface with DMA
? Ethernet transceiver interface
? Centronics printer port
? A32/D32 VMEbus interface
? VMEbus system controller
? Numerous control functions
Note that the Ethernet interface is not included on the MVME147-
010
