Memory Configuration Defaults.
The default configuration for Dynamic RAM mezzanine boards will position the mezzanine with
the largest memory size to start at the address selected with the ENV parameter "Base Address of
Dynamic Memory". The Base Address parameter defaults to 0. The smaller sized mezzanine will
follow immediately above the larger in the memory map. If mezzanines of the same size and type
are present, the first (closest to the board) is mapped to the selected base address. If mezzanines of
the same size but different type (parity and ECC) are present, the parity type will be mapped to the
selected base address and the ECC type mezzanine will follow. The SRAM does not default to a
location in the memory map that is contiguous with Dynamic RAMENV asks the following series of questions to set up the VMEbus interface for the MVME172
series modules. You should have a working knowledge of the VMEchip2 as given in the
MVME172 VME Embedded Controller Programmer’s Reference Guide in order to perform this
configuration. Also included in this series are questions for setting ROM and Flash access time.
The slave address decoders are used to allow another VMEbus master to access a local resource of
the MVME172LX. There are two slave address decoders set. They are set up as follows:Configuring the IndustryPacks
ENV asks the following series of questions to set up IndustryPack modules
(IPs) on MVME172LXs.
The MVME172 VME Embedded Controller Programmer’s Reference
Guide describes the base addresses and the IP register settings. Refer to
that manual for information on setting base addresses and register bits. Introduction
This chapter describes the MVME172LX VME embedded controller on a
block diagram level. The Description of Features provides an overview of
the MVME172LX, followed by a detailed description of several blocks of
circuitry. Figure 4-1 shows a block diagram of the overall board
architecture.
Detailed descriptions of other MVME172LX blocks, including
programmable registers in the ASICs and peripheral chips, can be found in
the MVME172 Embedded Controller Programmer’s Reference Guide
(part number VME172A/PG). Refer to it for a functional description of the
MVME172LX in greater depth.
