Introduction
This chapter provides a block diagram level description for the
MVME177 module. The functional description provides an
overview of the module, followed by a detailed description of
several blocks of the module. The block diagram of the MVME177
is shown in Figure 4-1 on page 4-3.
Descriptions of the other blocks of the MVME177, including
programmable registers in the ASICs and peripheral chips, are
given in the Single Board Computers Programmer's Reference Guide.
Refer to it for the rest of the functional description of the MVME177
module.
MVME177 Functional Description
The MVME177 is a high functionality VMEbus single board
computer designed around the MC68060 chip. The MVME177 has:
? 4/8/16/32/64/128/256MB of dynamic RAM
? SCSI mass storage interface
? Four serial ports
? One parallel port
? Ethernet transceiver interface
Data Bus Structure
The local data bus on the MVME177 is a 32-bit synchronous bus
that is based on the MC68060 bus, and supports burst transfers and
snooping. The various local bus master and slave devices use the local bus to communicate. The local bus is arbitrated by priority
type arbiter and the priority of the local bus masters from highest to
lowest is:
? 82596CA LAN
? CD2401 serial (through the PCCchip2)
? 53C710 SCSI
? VMEbus
? MPU
In the general case, any master can access any slave; however, not
all combinations pass the common sense test. Refer to the Single
Board Computers Programmer's Reference Guide and to the user's
guide for each device to determine:
? Port size
? Data bus connection
? Any restrictions that apply when accessing the device
